Low Dispersion Single Mode Fiber

Single Mode Fiber
December 29, 2025
Category Connection: Single Mode Fiber
Chat Now Contact Us
Tags:
#Fiber Optic Reel #Industrial Optic Fiber #5G Optical Fiber
Brief: Learn how this Low Dispersion Single Mode Fiber can streamline typical workflows and improve reliability in telecommunications and networking. This video provides a detailed walkthrough of its key performance characteristics, including its low attenuation and precise cladding geometry, demonstrating its suitability for long-distance, high-speed data transmission applications.
Related Product Features:
  • Features a cladding diameter of 125 ±0.7 microns with a roundness deviation of ≤1.0% for consistent optical performance.
  • Offers low attenuation rates, including 0.20 dB/km at 1550nm, ensuring high-quality data transmission over long distances.
  • Designed with a cut-off wavelength of ≤1260nm for efficient signal transmission with minimal distortion.
  • Exhibits low dispersion levels, less than 18 ps/(nm*km) at 1550nm, optimizing signal integrity.
  • Has a concentricity deviation of the core and cladding of ≤0.6um for reliable light signal travel.
  • Features a 250-micron coating diameter and a warpage of ≥4m for enhanced durability.
  • Operates effectively across a wide temperature range from -40°C to +85°C for versatile installations.
  • Supports various models including G.652D and G.657A1, ideal for high-speed data and telecommunications.
FAQs:
  • What are the key attenuation specifications for this single-mode fiber?
    The fiber features low attenuation rates of 0.33 dB/km at 1310nm, 0.34 dB/km at 1383nm, 0.20 dB/km at 1550nm, and 0.24 dB/km at 1625nm, ensuring minimal signal loss over long distances.
  • How does the cladding geometry contribute to the fiber's performance?
    With a cladding diameter of 125 ±0.7 microns and a roundness deviation of ≤1.0%, the fiber maintains consistent optical performance and signal integrity by minimizing light signal loss and distortion.
  • In what applications is this low dispersion single-mode fiber most suitable?
    It is ideal for telecommunications, networking, and data centers, especially for long-distance, high-speed data transmission where low dispersion and attenuation are critical for reliable performance.
  • What is the operating temperature range for this fiber optic cable?
    The fiber operates reliably in temperatures from -40°C to +85°C, making it suitable for both indoor and outdoor installations in various environmental conditions.
